MJ21193 数据手册
其他文档
未找到其他文档！
技术规格
- RoHS: true
- Category: Triode/MOS Tube/Transistor/Bipolar Transistors - BJT
- Datasheet: SPTECH MJ21193
- Transistor Type: PNP
- Operating Temperature: +200°C@(Tj)
- Collector Current (Ic): 16A
- Power Dissipation (Pd): 250W
- Transition Frequency (fT): 4MHz
- DC Current Gain (hFE@Ic,Vce): 25@8A,5V
- Collector Cut-Off Current (Icbo): -
- Collector-Emitter Breakdown Voltage (Vceo): 250V
- Collector-Emitter Saturation Voltage (VCE(sat)@Ic,Ib): 1.4V@8A,800mA
- Package: TO-204
- Manufacturer: SPTECH
- Part id: 4807
