SA30CA 数据手册
技术规格
- RoHS: true
- Category: TVS/Fuse/Board Level Protection/TVS
- Datasheet: Littelfuse SA30CA
- Breakdown Voltage: 33.3V
- Bidirectional Channels: 1
- Maximum Clamping Voltage: 48.4V
- Reverse Stand-Off Voltage (Vrwm): 30V
- Peak Pulse Current (Ipp)@10/1000us: 10.5A
- Peak Pulse Power Dissipation (Ppp)@10/1000us: 500W
- Package: DO-15(DO-204AC)
- Manufacturer: Littelfuse
- Part id: 483529
