9435 Datasheet
Datasheet specifications
|
Datasheet's name
|
9435
|
|
File size
|
70.314
KB
|
|
File type
|
pdf
|
|
Number of pages
|
5
|
Technical specifications
-
RoHS:
true
-
Type:
P Channel
-
Category:
Triode/MOS Tube/Transistor/MOSFETs
-
Datasheet:
KUU 9435
-
Operating Temperature:
+150°C@(Tj)
-
Power Dissipation (Pd):
2W
-
Total Gate Charge (Qg@Vgs):
22nC@15V
-
Drain Source Voltage (Vdss):
30V
-
Input Capacitance (Ciss@Vds):
845pF@15V
-
Continuous Drain Current (Id):
5.3A
-
Gate Threshold Voltage (Vgs(th)@Id):
3V@250uA
-
Reverse Transfer Capacitance (Crss@Vds):
80pF@15V
-
Drain Source On Resistance (RDS(on)@Vgs,Id):
57mΩ@10V,5.3A
-
Package:
SOP-8
-
Manufacturer:
KUU
-
Part id:
852837
