BTA20 Datasheet

BTA20

Datasheet specifications

Datasheet's name BTA20
File size 72.632 KB
File type pdf
Number of pages 4

Download Datasheet BTA20

Download Datasheet

Other documentations

BTA20 5 pages

Technical specifications

  • RoHS: true
  • Category: Triode/MOS Tube/Transistor/TRIACs
  • SCR Type: 1个双向可控硅
  • Datasheet: YFW BTA20
  • Holding Current (Ih): 75mA
  • Gate Trigger Current(Igt): 10mA
  • Gate Trigger Voltage (Vgt): 1.3V
  • RMS On-State Current(It (rms)): 20A
  • Peak Forward On?State Voltage (Vtm): 1.55V
  • Average Gate Power Dissipation (PG(AV)): 1W
  • Peak Repetitive Off?State Voltage (Vdrm): 800V
  • Peak non-repetitive surge current (Itsm@f): 210A@20ms
  • Package: TO-220
  • Manufacturer: YFW
  • Part id: 170490
