RXEF135-2 Datasheet
Datasheet specifications
|
Datasheet's name
|
RXEF135-2
|
|
File size
|
93.494
KB
|
|
File type
|
pdf
|
|
Number of pages
|
2
|
Technical specifications
-
RoHS:
true
-
Category:
TVS/Fuse/Board Level Protection/Resettable Fuses
-
Datasheet:
Littelfuse RXEF135-2
-
Hold Current:
1.35A
-
Trip Current:
2.7A
-
Power Dissipation:
1.7W
-
Current Rating (Max):
40A
-
Maximum Time to Trip:
9.6s
-
Operating Temperature:
-40°C~+85°C
-
Operating Voltage (Max):
72V
-
Resistance - Initial (Ri) (Min):
120mΩ
-
Resistance - Post Trip (R1) (Max):
300mΩ
-
Package:
Plugin
-
Manufacturer:
Littelfuse
-
Part id:
346784
