دیتاشیت SD24C
مشخصات دیتاشیت
| نام دیتاشیت |
SD24C
|
| حجم فایل |
148.58
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
7
|
مشخصات
-
RoHS:
true
-
Category:
TVS/Fuse/Board Level Protection/TVS
-
Datasheet:
Leiditech SD24C
-
Breakdown Voltage:
26.7V
-
Maximum Clamping Voltage:
47V
-
Reverse Stand-Off Voltage (Vrwm):
24V
-
Peak Pulse Current (Ipp)@10/1000us:
12A
-
Package:
SOD-323
-
Manufacturer:
Leiditech
-
Polarity:
Bi-Directional
-
Clamping Voltage@Ipp:
50V
-
Breakdown Voltage (VBR):
26.7V
-
Peak Pulse Current(Ipp)@8/20us:
6A
-
Number of Lines:
1
-
Operating Temperature:
-55°C~+150°C@(Tj)
-
Contact Discharge Vesd:
8kV
-
Reverse Leakage Current:
1uA
-
Peak Pulse Power(Ppp)@8/20us:
350W
-
Junction Capacitance(Cj)@1MHz:
50pF
-
Type:
-
-
Machine Model:
-
-
Human Body Model:
-
-
Part id:
42563
