P6SMB10A 数据手册
技术规格
- RoHS: true
- Category: TVS/Fuse/Board Level Protection/TVS
- Datasheet: FMS(Formosa Microsemi) P6SMB10A
- Breakdown Voltage: 9.5V
- Maximum Clamping Voltage: 14.5V
- Reverse Leakage Current (Ir): 10uA
- Reverse Stand-Off Voltage (Vrwm): 8.55V
- Peak Pulse Current (Ipp)@10/1000us: 41.4A
- Package: SMB(DO-214AA)
- Manufacturer: FMS(Formosa Microsemi)
- Unidirectional Channels: 1
- Peak Pulse Power Dissipation (Ppp)@10/1000us: 600W
- Part id: 596325
