دیتاشیت IXTA3N120
مشخصات دیتاشیت
| نام دیتاشیت |
IXTA3N120
|
| حجم فایل |
577.14
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
4
|
مشخصات
-
RoHS:
true
-
Category:
Triode/MOS Tube/Transistor/MOSFETs
-
Datasheet:
Littelfuse/IXYS IXTA3N120
-
Operating Temperature:
-55°C~+150°C@(Tj)
-
Power Dissipation (Pd):
200W
-
Total Gate Charge (Qg@Vgs):
42nC@10V
-
Drain Source Voltage (Vdss):
1200V
-
Input Capacitance (Ciss@Vds):
1350pF@25V
-
Continuous Drain Current (Id):
3A
-
Gate Threshold Voltage (Vgs(th)@Id):
5V@250uA
-
Reverse Transfer Capacitance (Crss@Vds):
-
-
Drain Source On Resistance (RDS(on)@Vgs,Id):
4.5Ω@1.5A,10V
-
Package:
TO-263
-
Manufacturer:
IXYS
-
Part id:
99667
