دیتاشیت AO3400
مشخصات دیتاشیت
| نام دیتاشیت |
AO3400
|
| حجم فایل |
118.99
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
4
|
مشخصات
-
RoHS:
true
-
Category:
Triode/MOS Tube/Transistor/MOSFETs
-
Datasheet:
TECH PUBLIC AO3400
-
Package:
SOT-23-3L
-
Manufacturer:
TECH PUBLIC
-
Type:
N Channel
-
Operating Temperature:
-55°C~+150°C@(Tj)
-
Power Dissipation (Pd):
1.4W
-
Total Gate Charge (Qg@Vgs):
9.5nC@4.5V
-
Drain Source Voltage (Vdss):
30V
-
Input Capacitance (Ciss@Vds):
820pF@15V
-
Continuous Drain Current (Id):
5.8A
-
Gate Threshold Voltage (Vgs(th)@Id):
900mV@250uA
-
Reverse Transfer Capacitance (Crss@Vds):
77pF@15V
-
Drain Source On Resistance (RDS(on)@Vgs,Id):
28mΩ@10V,5.8A
-
Part id:
136084
