15N10 دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
15N10
|
|
حجم فایل
|
61.205
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
5
|
مشخصات فنی
-
RoHS:
true
-
Type:
N Channel
-
Category:
Triode/MOS Tube/Transistor/MOSFETs
-
Datasheet:
UMW(Youtai Semiconductor Co., Ltd.) 15N10
-
Operating Temperature:
-55°C~+175°C@(Tj)
-
Power Dissipation (Pd):
55W
-
Total Gate Charge (Qg@Vgs):
19.2nC@10V
-
Drain Source Voltage (Vdss):
100V
-
Input Capacitance (Ciss@Vds):
632pF@50V
-
Continuous Drain Current (Id):
15A
-
Gate Threshold Voltage (Vgs(th)@Id):
3V@250uA
-
Reverse Transfer Capacitance (Crss@Vds):
-
-
Drain Source On Resistance (RDS(on)@Vgs,Id):
80mΩ@10V,10A
-
Package:
TO-252
-
Manufacturer:
UMW(Youtai Semiconductor Co., Ltd.)
-
Part id:
1227842
