STP15NK50Z دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
STP15NK50Z
|
|
حجم فایل
|
517.764
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
19
|
مشخصات فنی
-
RoHS:
true
-
Category:
Triode/MOS Tube/Transistor/MOSFETs
-
Datasheet:
STMicroelectronics STP15NK50Z
-
Operating Temperature:
-50°C~+150°C@(Tj)
-
Power Dissipation (Pd):
160W
-
Total Gate Charge (Qg@Vgs):
106nC@10V
-
Drain Source Voltage (Vdss):
500V
-
Input Capacitance (Ciss@Vds):
2260pF@25V
-
Continuous Drain Current (Id):
14A
-
Gate Threshold Voltage (Vgs(th)@Id):
4.5V@100uA
-
Reverse Transfer Capacitance (Crss@Vds):
-
-
Drain Source On Resistance (RDS(on)@Vgs,Id):
340mΩ@7A,10V
-
Package:
TO-220
-
Manufacturer:
STMicroelectronics
-
Part id:
246326
