دیتاشیت SD05C
مشخصات دیتاشیت
| نام دیتاشیت |
SD05C
|
| حجم فایل |
719.538
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
4
|
مشخصات
-
RoHS:
true
-
Category:
TVS/Fuse/Board Level Protection/ESD Protection Devices
-
Datasheet:
MSKSEMI SD05C
-
Package:
SOD-323
-
Manufacturer:
MSKSEMI
-
Clamping Voltage@Ipp:
18V
-
Breakdown Voltage (VBR):
6V
-
Reverse Leakage Current:
10uA
-
Peak Pulse Power(Ppp)@8/20us:
350W
-
Junction Capacitance(Cj)@1MHz:
200pF
-
Reverse Stand-Off Voltage (Vrwm):
5V
-
Polarity:
-
-
Peak Pulse Current(Ipp)@8/20us:
17A
-
Number of Lines:
1
-
Machine Model:
±30kV
-
Human Body Model:
±30kV
-
Operating Temperature:
-55°C~+125°C
-
Contact Discharge Vesd:
±30kV
-
Breakdown Voltage:
6V
-
Maximum Clamping Voltage:
17V
-
Peak Pulse Current (Ipp)@10/1000us:
15A
-
Reverse Leakage Current (Ir):
10uA
-
Part id:
530861
