SMAJ45CA 数据手册
技术规格
- RoHS: true
- Category: TVS/Fuse/Board Level Protection/TVS
- Datasheet: DOWO SMAJ45CA
- Breakdown Voltage: 50V
- Maximum Clamping Voltage: 72.7V
- Reverse Stand-Off Voltage (Vrwm): 45V
- Peak Pulse Current (Ipp)@10/1000us: 5.5A
- Package: SMA(DO-214AC)
- Manufacturer: DOWO
- Bidirectional Channels: 1
- Reverse Leakage Current (Ir): 1uA
- Peak Pulse Power Dissipation (Ppp)@10/1000us: 400W
- Unidirectional Channels: 0
- Part id: 1245880
