SM03 Datasheet
Datasheet specifications
|
Datasheet's name
|
SM03
|
|
File size
|
64.795
KB
|
|
File type
|
pdf
|
|
Number of pages
|
3
|
Technical specifications
-
RoHS:
true
-
Category:
TVS/Fuse/Board Level Protection/ESD Protection Devices
-
Polarity:
Unidirectional
-
Datasheet:
KUU SM03
-
Number of Lines:
2
-
Clamping Voltage@Ipp:
14V
-
Operating Temperature:
-55°C~+150°C@(Tj)
-
Contact Discharge Vesd:
8kV
-
Breakdown Voltage (VBR):
4V
-
Reverse Leakage Current:
1uA
-
Peak Pulse Power(Ppp)@8/20us:
350W
-
Junction Capacitance(Cj)@1MHz:
450pF
-
Peak Pulse Current(Ipp)@8/20us:
20A
-
Reverse Stand-Off Voltage (Vrwm):
3.3V
-
Package:
SOT-23
-
Manufacturer:
KUU
-
Breakdown Voltage:
4V
-
Maximum Clamping Voltage:
14V
-
Peak Pulse Current (Ipp)@10/1000us:
20A
-
Part id:
775105
