MF-FSMF050X-2 Datasheet

MF-FSMF050X-2

Datasheet specifications

Datasheet's name MF-FSMF050X-2
File size 270.575 KB
File type pdf
Number of pages 4

Download Datasheet MF-FSMF050X-2

Download Datasheet

Other documentations

MF-FSMF020X-2 4 pages

Technical specifications

  • RoHS: true
  • Category: TVS/Fuse/Board Level Protection/Resettable Fuses
  • Datasheet: BOURNS MF-FSMF050X-2
  • Hold Current: 500mA
  • Trip Current: 1A
  • Current Rating (Max): 40A
  • Maximum Time to Trip: 100ms
  • Operating Temperature: -40°C~+85°C
  • Operating Voltage (Max): 6V
  • Resistance - Initial (Ri) (Min): 100mΩ
  • Resistance - Post Trip (R1) (Max): 800mΩ
  • Package: 0603
  • Manufacturer: BOURNS
  • Part id: 521136
