CH561Q دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
CH561Q
|
|
حجم فایل
|
17.225
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
96
|
مشخصات فنی
-
CAN:
-
-
I2C:
-
-
I2S:
-
-
SPI:
2
-
RoHS:
true
-
EEPROM:
-
-
CPU Core:
RISC
-
Category:
Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
-
RAM Size:
32KB
-
Watchdog:
Yes
-
ADC (Bit):
10bit
-
DAC (Bit):
-
-
Datasheet:
WCH(Jiangsu Qin Heng) CH561Q
-
PWM (Bit):
-
-
8Bit Timer:
-
-
UART/USART:
2
-
16Bit Timer:
-
-
32Bit Timer:
-
-
Real-Time Clock:
-
-
CPU Maximum Speed:
130MHz
-
GPIO Ports Number:
27
-
Low-Voltage Detect:
-
-
CCP Capture/Compare:
Yes
-
Internal Comparator:
-
-
Internal Oscillator:
-
-
Peripheral/Function:
DMA;CCP capture/compare;IrDA;WDT;Ethernet protocol stack;28BitTimer
-
Program Memory Type:
FLASH
-
Direct Memory Access:
Yes
-
Program Storage Size:
64KB
-
Universal Serial Bus:
-
-
communication protocol:
以太网协议
-
Operating Voltage Range:
3V~3.6V
-
Infrared Data Association:
Yes
-
Operating Temperature Range:
-40°C~+85°C
-
Secure Digital Input and Output:
-
-
Package:
LQFP-64(10x10)
-
Manufacturer:
WCH(Jiangsu Qin Heng)
-
Part id:
1148596
