SMF13A 数据手册
技术规格
- RoHS: true
- Category: TVS/Fuse/Board Level Protection/TVS
- Datasheet: GOODWORK SMF13A
- Breakdown Voltage: 14.4V
- Maximum Clamping Voltage: 21.5V
- Reverse Leakage Current (Ir): 1uA
- Reverse Stand-Off Voltage (Vrwm): 13V
- Peak Pulse Current (Ipp)@10/1000us: 9.3A
- Package: SOD-123FL
- Manufacturer: GOODWORK
- Unidirectional Channels: 1
- Peak Pulse Power Dissipation (Ppp)@10/1000us: 200W
- Peak Pulse Current (Ipp)@10/1000μs: 9.3A
- Part id: 593243
