AHRF450 数据手册
其他文档
AHRF300 10 pages
技术规格
- RoHS: true
- Category: TVS/Fuse/Board Level Protection/Resettable Fuses
- Datasheet: Littelfuse AHRF450
- Hold Current: 4.5A
- Trip Current: 8.7A
- Power Dissipation: 3.6W
- Current Rating (Max): 100A
- Maximum Time to Trip: 4s
- Operating Temperature: -40°C~+125°C
- Operating Voltage (Max): 16V
- Resistance - Initial (Ri) (Min): 17mΩ
- Resistance - Post Trip (R1) (Max): 54mΩ
- Package: Plugin
- Manufacturer: Littelfuse
- Part id: 952861
