7580D دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
7580D
|
|
حجم فایل
|
82.905
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
6
|
مشخصات فنی
-
RoHS:
true
-
Type:
N Channel
-
Category:
Triode/MOS Tube/Transistor/MOSFETs
-
Datasheet:
Shenzhen Fuman Elec 7580D
-
Operating Temperature:
-55°C~+175°C@(Tj)
-
Power Dissipation (Pd):
147W
-
Total Gate Charge (Qg@Vgs):
115nC@10V
-
Drain Source Voltage (Vdss):
75V
-
Input Capacitance (Ciss@Vds):
5053pF@25V
-
Continuous Drain Current (Id):
86A
-
Gate Threshold Voltage (Vgs(th)@Id):
4V@250uA
-
Reverse Transfer Capacitance (Crss@Vds):
145pF@25V
-
Drain Source On Resistance (RDS(on)@Vgs,Id):
7mΩ@10V,40A
-
Package:
TO-263-2
-
Manufacturer:
Shenzhen Fuman Elec
-
Part id:
1145039
