AK1-076C 数据手册
其他文档
AK1-076C 1 pages
技术规格
- RoHS: true
- Category: TVS/Fuse/Board Level Protection/ESD Protection Devices
- Datasheet: Littelfuse AK1-076C
- Number of Lines: 1
- Clamping Voltage@Ipp: 140V
- Operating Temperature: -55°C~+125°C@(Tj)
- Breakdown Voltage (VBR): 85V
- Peak Pulse Power(Ppp)@8/20us: -
- Junction Capacitance(Cj)@1MHz: 8500pF@10kHz
- Peak Pulse Current(Ipp)@8/20us: 1kA@(8/20us)
- Reverse Stand-Off Voltage (Vrwm): 76V
- Package: -
- Manufacturer: Littelfuse
- Part id: 1282849
