دیتاشیت 8205S
مشخصات دیتاشیت
| نام دیتاشیت |
8205S
|
| حجم فایل |
336.927
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
3
|
مشخصات
-
RoHS:
true
-
Type:
2PCSNChannel(Common Drain)
-
Category:
Triode/MOS Tube/Transistor/MOSFETs
-
Datasheet:
JSMSEMI 8205S
-
Operating Temperature:
-55°C~+150°C@(Tj)
-
Power Dissipation (Pd):
2W
-
Total Gate Charge (Qg@Vgs):
6.24nC@4.5V
-
Drain Source Voltage (Vdss):
20V
-
Input Capacitance (Ciss@Vds):
522.3pF@8V
-
Continuous Drain Current (Id):
6A
-
Gate Threshold Voltage (Vgs(th)@Id):
1.5V@250uA
-
Reverse Transfer Capacitance (Crss@Vds):
74.69pF@8V
-
Drain Source On Resistance (RDS(on)@Vgs,Id):
20mΩ@10V,5A
-
Package:
SOT-23-6
-
Manufacturer:
JSMSEMI
-
Part id:
1146800
