دیتاشیت ESD5Z3V3
مشخصات دیتاشیت
| نام دیتاشیت |
ESD5Z3V3
|
| حجم فایل |
166.622
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
2
|
مشخصات
-
RoHS:
true
-
Category:
TVS/Fuse/Board Level Protection/ESD Protection Devices
-
Datasheet:
TWGMC ESD5Z3V3
-
Package:
SOD-523
-
Manufacturer:
TWGMC
-
Breakdown Voltage:
5V
-
Maximum Clamping Voltage:
14.1V
-
Reverse Stand-Off Voltage (Vrwm):
3.3V@Max
-
Peak Pulse Current (Ipp)@10/1000us:
11.2A
-
Polarity:
Unidirectional
-
Number of Lines:
1
-
Clamping Voltage@Ipp:
14V
-
Operating Temperature:
-55°C~+125°C@(Tj)
-
Contact Discharge Vesd:
22kV
-
Breakdown Voltage (VBR):
5V
-
Reverse Leakage Current:
0.9uA
-
Peak Pulse Power(Ppp)@8/20us:
105W
-
Junction Capacitance(Cj)@1MHz:
105pF
-
Peak Pulse Current(Ipp)@8/20us:
7.5A
-
Part id:
1022999
