دیتاشیت PESD24VS1UB
مشخصات دیتاشیت
| نام دیتاشیت |
PESD24VS1UB
|
| حجم فایل |
112.39
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
15
|
مشخصات
-
RoHS:
true
-
Category:
TVS/Fuse/Board Level Protection/ESD Protection Devices
-
Polarity:
Bi-Directional
-
Datasheet:
DOWO PESD24VS1UB
-
Machine Model:
±30kV
-
Number of Lines:
1
-
Human Body Model:
±30kV
-
Clamping Voltage@Ipp:
40V
-
Operating Temperature:
-55°C~+125°C
-
Contact Discharge Vesd:
±30kV
-
Breakdown Voltage (VBR):
26V
-
Reverse Leakage Current:
0.5uA
-
Peak Pulse Power(Ppp)@8/20us:
420W
-
Junction Capacitance(Cj)@1MHz:
30pF
-
Peak Pulse Current(Ipp)@8/20us:
9A
-
Reverse Stand-Off Voltage (Vrwm):
24V
-
Package:
SOD-523
-
Manufacturer:
DOWO
-
Part id:
101398
