PQ2617BHA-150K 数据手册
其他文档
PQ2617BHA-150K 1 pages
技术规格
- RoHS: true
- Type: -
- Ratings: AEC-Q200
- Category: Inductors/Coils/Transformers/Power Inductors
- Datasheet: BOURNS PQ2617BHA-150K
- Tolerance: ±10%
- Inductance: 15uH
- Rated Current: -
- DC Resistance (DCR): 2.16mΩ
- Saturation Current (Isat): 21.2A
- Package: SMD,19.8x27.9mm
- Manufacturer: BOURNS
- Part id: 993699
