BC869 数据手册
其他文档
BC869-16 2 pages
技术规格
- RoHS: true
- Category: Triode/MOS Tube/Transistor/Bipolar Transistors - BJT
- Datasheet: Shikues BC869
- Transistor Type: PNP
- Operating Temperature: +150°C@(Tj)
- Collector Current (Ic): 1A
- Power Dissipation (Pd): 1.2W
- Transition Frequency (fT): 140MHz
- DC Current Gain (hFE@Ic,Vce): 50@5mA,10V
- Collector Cut-Off Current (Icbo): 100nA
- Collector-Emitter Breakdown Voltage (Vceo): 20V
- Collector-Emitter Saturation Voltage (VCE(sat)@Ic,Ib): 500mV@1A,100mA
- Package: SOT-89
- Manufacturer: Shikues
- Part id: 923461
