SMAJ18A Datasheet
Datasheet specifications
| Datasheet's name | SMAJ18A |
|---|---|
| File size | 65.659 KB |
| File type | |
| Number of pages | 5 |
Download Datasheet SMAJ18A |
Download Datasheet |
|---|
Other documentations
SMAJ60A 7 pages
SMAJ60A 5 pages
SMAJ60A 4 pages
SMAJ60A 4 pages
SMAJ60A 4 pages
SMAJ60A 6 pages
SMAJ60A 5 pages
SMAJ60A 6 pages
SMAJ58A 5 pages
SMAJ58A 5 pages
SMAJ58A 3 pages
SMAJ58A 7 pages
SMAJ58A 4 pages
SMAJ58A 5 pages
SMAJ170A 4 pages
SMAJ24A 6 pages
SMAJ24A 4 pages
SMAJ24A 5 pages
SMAJ15A 7 pages
SMAJ18A 4 pages
SMAJ18A 4 pages
SMAJ18A 16 pages
Technical specifications
- RoHS: true
- Category: TVS/Fuse/Board Level Protection/TVS
- Datasheet: SEMIWARE SMAJ18A
- Breakdown Voltage: 20V
- Maximum Clamping Voltage: 29.2V
- Reverse Leakage Current (Ir): 1uA
- Reverse Stand-Off Voltage (Vrwm): 18V
- Peak Pulse Current (Ipp)@10/1000us: 13.7A
- Package: SMA(DO-214AC)
- Manufacturer: SEMIWARE
- Unidirectional Channels: 1
- Peak Pulse Power Dissipation (Ppp)@10/1000us: 400W
- Part id: 342466
