دیتاشیت DTC124ECA

DTC124ECA

مشخصات دیتاشیت

نام دیتاشیت DTC124ECA
حجم فایل 375.644 کیلوبایت
نوع فایل pdf
تعداد صفحات 3

دانلود دیتاشیت DTC124ECA

DTC124ECA Datasheet

مشخصات

  • RoHS: true
  • Category: Triode/MOS Tube/Transistor/Digital Transistors
  • Datasheet: Jiangsu Changjing Electronics Technology Co., Ltd. DTC124ECA
  • Transistor Type: 1 NPN - Pre Biased
  • Collector Current (Ic): 30mA
  • Power Dissipation (Pd): 200mW
  • Collector-Emitter Breakdown Voltage (Vceo): 50V
  • Package: SOT-23
  • Manufacturer: Jiangsu Changjing Electronics Technology Co., Ltd.
  • Input Resistor: 22kΩ
  • Resistor Ratio: 1
  • Operating Temperature: +150°C@(Tj)
  • Transition Frequency (fT): 250MHz
  • DC Current Gain (hFE@Ic,Vce): 56@5mA,5V
  • Input Voltage (VI(on)@Ic,Vce): 3V@5mA,0.2V
  • Output Voltage (VO(on)@Io/Ii): 0.3V@10mA,0.5mA
  • Input Voltage (VI(off)@Ic,Vce): 0.5V@100uA,5V
  • Collector Cut-Off Current (Icbo): 500nA
  • Collector-Emitter Saturation Voltage (VCE(sat)@Ic,Ib): 300mV@500uA,10mA
  • Part id: 339839
