ZX5T955GTA دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
ZX5T955GTA
|
|
حجم فایل
|
76.874
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
7
|
مشخصات فنی
-
RoHS:
true
-
Category:
Triode/MOS Tube/Transistor/Bipolar Transistors - BJT
-
Datasheet:
Diodes Incorporated ZX5T955GTA
-
Transistor Type:
PNP
-
Operating Temperature:
-55°C~+150°C@(Tj)
-
Collector Current (Ic):
4A
-
Power Dissipation (Pd):
3W
-
Transition Frequency (fT):
120MHz
-
DC Current Gain (hFE@Ic,Vce):
100@1A,5V
-
Collector Cut-Off Current (Icbo):
20nA
-
Collector-Emitter Breakdown Voltage (Vceo):
140V
-
Collector-Emitter Saturation Voltage (VCE(sat)@Ic,Ib):
275mV@3A,300mA
-
Package:
SOT-223
-
Manufacturer:
Diodes Incorporated
-
Part id:
108105
