CD54T125NP-560KC 数据手册
其他文档
CD54T125NP-560KC 4 pages
技术规格
- RoHS: true
- Ratings: AEC-Q200
- Category: Inductors/Coils/Transformers/Power Inductors
- Datasheet: Sumida CD54T125NP-560KC
- Tolerance: ±10%
- Inductance: 56uH
- Rated Current: 700mA
- DC Resistance (DCR): 278mΩ
- Saturation Current (Isat): 700mA
- Package: -
- Manufacturer: Sumida
- Part id: 840931
