SF58 Datasheet
Datasheet specifications
| Datasheet's name | SF58 |
|---|---|
| File size | 95.686 KB |
| File type | |
| Number of pages | 2 |
Download Datasheet SF58 |
Download Datasheet |
|---|
Other documentations
No other documentation was found!
Technical specifications
- RoHS: true
- Category: Diodes/Diodes - Fast Recovery Rectifiers
- Datasheet: LGE SF58
- Diode Configuration: -
- Reverse Voltage (Vr): 600V
- Operating Temperature: -65°C~+125°C@(Tj)
- Forward Voltage (Vf@If): 1.7V@5A
- Reverse Leakage Current: 5uA@600V
- Reverse Recovery Time (trr): 35ns
- Average Rectified Current (Io): 5A
- Package: DO-27
- Manufacturer: LGE
