5KP33CA 数据手册
技术规格
- RoHS: true
- Category: TVS/Fuse/Board Level Protection/TVS
- Datasheet: DOWO 5KP33CA
- Breakdown Voltage: 36.7V
- Maximum Clamping Voltage: 53.3V
- Reverse Stand-Off Voltage (Vrwm): 33V
- Peak Pulse Current (Ipp)@10/1000us: 93.8A
- Package: P600
- Manufacturer: DOWO
- Bidirectional Channels: 1
- Peak Pulse Power Dissipation (Ppp)@10/1000us: 5kW
- Reverse Leakage Current (Ir): 2uA
