SMAJ13CA 数据手册
技术规格
- RoHS: true
- Category: TVS/Fuse/Board Level Protection/TVS
- Datasheet: TWGMC SMAJ13CA
- Package: SMA
- Manufacturer: TWGMC
- Breakdown Voltage: 14.4V
- Maximum Clamping Voltage: 21.5V
- Reverse Stand-Off Voltage (Vrwm): 13V
- Peak Pulse Current (Ipp)@10/1000us: 18.6A
- Bidirectional Channels: 1
- Reverse Leakage Current (Ir): 1uA
- Peak Pulse Power Dissipation (Ppp)@10/1000us: 400W
- Peak Pulse Current (Ipp)@10/1000μs: 18.6A
