دیتاشیت SMAJ20CA
مشخصات دیتاشیت
| نام دیتاشیت |
SMAJ20CA
|
| حجم فایل |
61.773
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
3
|
مشخصات فنی
-
RoHS:
true
-
Category:
TVS/Fuse/Board Level Protection/TVS
-
Datasheet:
Yangzhou Yangjie Elec Tech SMAJ20CA
-
Breakdown Voltage:
22.2V
-
Bidirectional Channels:
1
-
Maximum Clamping Voltage:
32.4V
-
Reverse Stand-Off Voltage (Vrwm):
20V
-
Peak Pulse Current (Ipp)@10/1000us:
12.35A
-
Peak Pulse Power Dissipation (Ppp)@10/1000us:
400W
-
Package:
SMA(DO-214AC)
-
Manufacturer:
Yangzhou Yangjie Elec Tech
-
Reverse Leakage Current (Ir):
1uA
-
Peak Pulse Current (Ipp)@10/1000μs:
12.4A
-
Peak Pulse Power Dissipation (Ppp)@10/1000μs:
400W
