P4SMA30A 数据手册
其他文档
P4SMA6.8A 6 pages
技术规格
- RoHS: true
- Category: TVS/Fuse/Board Level Protection/TVS
- Datasheet: Littelfuse P4SMA30A
- Breakdown Voltage: 28.5V
- Unidirectional Channels: 1
- Maximum Clamping Voltage: 41.4V
- Reverse Stand-Off Voltage (Vrwm): 25.6V
- Peak Pulse Current (Ipp)@10/1000us: 9.9A
- Peak Pulse Power Dissipation (Ppp)@10/1000us: 400W
- Package: SMA(DO-214AC)
- Manufacturer: Littelfuse
- Reverse Leakage Current (Ir): 1uA
