SMDJ100CA 数据手册
技术规格
- RoHS: true
- Category: TVS/Fuse/Board Level Protection/TVS
- Datasheet: Yint SMDJ100CA
- Package: SMC(DO-214AB)
- Manufacturer: Yint
- Breakdown Voltage: 111V
- Maximum Clamping Voltage: 162V
- Reverse Stand-Off Voltage (Vrwm): 100V
- Peak Pulse Current (Ipp)@10/1000us: 18.5A
- Reverse Leakage Current (Ir): 5uA
- Bidirectional Channels: 1
- Peak Pulse Current (Ipp)@10/1000μs: 18.5A
- Peak Pulse Power Dissipation (Ppp)@10/1000μs: 3kW
