AO3404A Datasheet
Datasheet specifications
|
Datasheet's name
|
AO3404A
|
|
File size
|
67.564
KB
|
|
File type
|
pdf
|
|
Number of pages
|
4
|
Technical specifications
-
RoHS:
true
-
Type:
N Channel
-
Category:
Triode/MOS Tube/Transistor/MOSFETs
-
Datasheet:
Alpha & Omega Semicon AO3404A
-
Operating Temperature:
-55°C~+150°C@(Tj)
-
Power Dissipation (Pd):
1.4W
-
Total Gate Charge (Qg@Vgs):
17nC@10V
-
Drain Source Voltage (Vdss):
30V
-
Input Capacitance (Ciss@Vds):
820pF@15V
-
Continuous Drain Current (Id):
5.8A
-
Gate Threshold Voltage (Vgs(th)@Id):
3V@250uA
-
Drain Source On Resistance (RDS(on)@Vgs,Id):
28mΩ@10V,5.8A
-
Package:
SOT-23-3L
-
Manufacturer:
Alpha & Omega Semicon
