دیتاشیت DMC1229UFDB-7
مشخصات دیتاشیت
| نام دیتاشیت |
DMC1229UFDB-7
|
| حجم فایل |
85.427
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
9
|
مشخصات
-
RoHS:
true
-
Type:
1PCSN-Channel&1PCSP-Channel
-
Category:
Triode/MOS Tube/Transistor/MOSFETs
-
Datasheet:
Diodes Incorporated DMC1229UFDB-7
-
Operating Temperature:
-55°C~+150°C@(Tj)
-
Power Dissipation (Pd):
1.4W
-
Total Gate Charge (Qg@Vgs):
10.5nC@4.5V;10.7nC@4.5V
-
Drain Source Voltage (Vdss):
12V
-
Input Capacitance (Ciss@Vds):
914pF@6V;915pF@6V
-
Continuous Drain Current (Id):
5.6A;3.8A
-
Gate Threshold Voltage (Vgs(th)@Id):
1V@250uA
-
Reverse Transfer Capacitance (Crss@Vds):
119pF@6V;183pF@6V
-
Drain Source On Resistance (RDS(on)@Vgs,Id):
17mΩ@4.5V,5A;37mΩ@4.5V,3.6A
-
Package:
DFN-6(2x2)
-
Manufacturer:
Diodes Incorporated
