JK16-400 数据手册
其他文档
JK16-300 6 pages
技术规格
- RoHS: true
- Category: TVS/Fuse/Board Level Protection/Resettable Fuses
- Datasheet: Jinrui Electronic Materials Co. JK16-400
- Hold Current: 4A
- Trip Current: 8A
- Current Rating (Max): 100A
- Maximum Time to Trip: 15s
- Operating Voltage (Max): 16V
- Package: Plugin
- Manufacturer: Jinrui Electronic Materials Co.
- Power Dissipation: -
- Operating Temperature: -
- Resistance - Initial (Ri) (Min): -
- Resistance - Post Trip (R1) (Max): -
