M74VHC1G132DFT2G دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
M74VHC1G132DFT2G
|
|
حجم فایل
|
79.195
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
14
|
مشخصات فنی
-
RoHS:
true
-
Series:
74VHC
-
Category:
Logic ICs/Gates
-
Datasheet:
onsemi M74VHC1G132DFT2G
-
Sink Current:
8mA
-
Source Current:
8mA
-
Supply Voltage:
2V~5.5V
-
Logic Gate Type:
NAND Gates
-
Number of Channels:
1
-
Low Level Range (VIL):
0.65V~1.45V
-
Operating Temperature:
-55°C~+125°C
-
High Level Range (VIH):
2.25V~3.7V
-
Propagation Delay Time:
9.7ns@5V,50pF
-
Quiescent Current (Max):
1uA
-
Package:
SC-70
-
Manufacturer:
onsemi
