BAV21WSQ 数据手册
其他文档
未找到其他文档！
技术规格
- RoHS: true
- Category: Diodes/Switching Diode
- Datasheet: Yangzhou Yangjie Elec Tech BAV21WSQ
- Power Dissipation: 250mW
- Diode Configuration: Single
- Reverse Voltage (Vr): 250V
- Operating Temperature: +150°C@(Tj)
- Forward Voltage (Vf@If): 1.25V@200mA
- Reverse Leakage Current: 100nA@200V
- Reverse Recovery Time (trr): 50ns
- Average Rectified Current (Io): 200mA
- Package: SOD-323
- Manufacturer: Yangzhou Yangjie Elec Tech
