74LVC2G14GW,125 دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
74LVC2G14GW,125
|
|
حجم فایل
|
37.962
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
17
|
مشخصات فنی
-
RoHS:
true
-
Series:
74LVC
-
Category:
Logic ICs/Inverters
-
Datasheet:
Nexperia 74LVC2G14GW,125
-
Input Type:
Schmitt Trigger
-
Sink Current:
32mA
-
Source Current:
32mA
-
Number of Inputs:
2
-
Number of Circuits:
2
-
Supply Current (Max):
4uA
-
Low level range (VIL):
0.25V~1.2V
-
Max Propagation Delay:
4.7ns@5V,50pF
-
Operating Temperature:
-40°C~+125°C
-
High level range (VIH):
1.5V~3.6V
-
Supply Voltage(Single):
1.65V~5.5V
-
Package:
SOT-363-6(SC-70-6)
-
Manufacturer:
Nexperia
