GBLC05CI دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
GBLC05CI
|
|
حجم فایل
|
45.479
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
4
|
مشخصات فنی
-
RoHS:
true
-
Category:
TVS/Fuse/Board Level Protection/TVS
-
Breakdown Voltage:
9.8V
-
Bidirectional Channels:
1
-
Unidirectional Channels:
-
-
Maximum Clamping Voltage:
9.8V
-
Reverse Leakage Current (Ir):
1uA
-
Reverse Stand-Off Voltage (Vrwm):
5V
-
Peak Pulse Current (Ipp)@10/1000us:
18A
-
Peak Pulse Power Dissipation (Ppp)@10/1000us:
350W
-
Package:
SOD-323
-
Manufacturer:
Shikues
-
Datasheet:
Slkor(SLKORMICRO Elec.) GBLC05CI
-
Clamping Voltage@Ipp:
20V
-
Breakdown Voltage (VBR):
6V
-
Reverse Leakage Current:
1uA
-
Peak Pulse Power(Ppp)@8/20us:
350W
-
Junction Capacitance(Cj)@1MHz:
0.8pF
-
Polarity:
Bi-Directional
-
Number of Lines:
2
-
Operating Temperature:
-55°C~+150°C@(Tj)
-
Contact Discharge Vesd:
8kV
-
Peak Pulse Current(Ipp)@8/20us:
18A
