技术规格
- RoHS: true
- Category: TVS/Fuse/Board Level Protection/Resettable Fuses
- Datasheet: Littelfuse FEMTOSMDC010F-2
- Hold Current: 100mA
- Trip Current: 250mA
- Power Dissipation: 0.5W
- Current Rating (Max): 40A
- Maximum Time to Trip: 100ms
- Operating Temperature: -40°C~+85°C
- Operating Voltage (Max): 12V
- Resistance - Initial (Ri) (Min): 1.7Ω
- Resistance - Post Trip (R1) (Max): 8Ω
- Package: 0603
- Manufacturer: Littelfuse
