WSD100N06GDN56 دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
WSD100N06GDN56
|
|
حجم فایل
|
75.003
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
5
|
مشخصات فنی
-
RoHS:
true
-
Type:
N Channel
-
Category:
Triode/MOS Tube/Transistor/MOSFETs
-
Datasheet:
Winsok Semicon WSD100N06GDN56
-
Operating Temperature:
+150°C@(Tj)
-
Power Dissipation (Pd):
83W
-
Total Gate Charge (Qg@Vgs):
58nC@10V
-
Drain Source Voltage (Vdss):
60V
-
Input Capacitance (Ciss@Vds):
3.458nF@30V
-
Continuous Drain Current (Id):
100A
-
Gate Threshold Voltage (Vgs(th)@Id):
1.8V@250uA
-
Reverse Transfer Capacitance (Crss@Vds):
22pF@30V
-
Drain Source On Resistance (RDS(on)@Vgs,Id):
3mΩ@10V,20A
-
Package:
DFN-8-EP(5.8x5.3)
-
Manufacturer:
Winsok Semicon
