RU30L15H-VB دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
RU30L15H-VB
|
|
حجم فایل
|
73.672
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
9
|
مشخصات فنی
-
RoHS:
true
-
Type:
P Channel
-
Category:
Triode/MOS Tube/Transistor/MOSFETs
-
Datasheet:
VBsemi Elec RU30L15H-VB
-
Operating Temperature:
-55°C~+150°C@(Tj)
-
Power Dissipation (Pd):
5.6W
-
Total Gate Charge (Qg@Vgs):
22nC@4.5V
-
Drain Source Voltage (Vdss):
30V
-
Input Capacitance (Ciss@Vds):
1.96nF@15V
-
Continuous Drain Current (Id):
11.6A
-
Gate Threshold Voltage (Vgs(th)@Id):
3V@250uA
-
Reverse Transfer Capacitance (Crss@Vds):
325pF@15V
-
Drain Source On Resistance (RDS(on)@Vgs,Id):
11mΩ@10V,10A
-
Package:
SOP-8
-
Manufacturer:
VBsemi Elec
