MD20N60 Datasheet
Datasheet specifications
| Datasheet's name | MD20N60 |
|---|---|
| File size | 69.593 KB |
| File type | |
| Number of pages | 15 |
Download Datasheet MD20N60 |
Download Datasheet |
|---|
Other documentations
No other documentation was found!
Technical specifications
- RoHS: true
- Type: N Channel
- Category: Triode/MOS Tube/Transistor/MOSFETs
- Datasheet: Minos MD20N60
- Operating Temperature: +150°C@(Tj)
- Power Dissipation (Pd): 300W
- Total Gate Charge (Qg@Vgs): 62nC@10V
- Drain Source Voltage (Vdss): 600V
- Input Capacitance (Ciss@Vds): 3120pF@25V
- Continuous Drain Current (Id): 20A
- Gate Threshold Voltage (Vgs(th)@Id): 4V@250uA
- Reverse Transfer Capacitance (Crss@Vds): 15pF@25V
- Drain Source On Resistance (RDS(on)@Vgs,Id): 390mΩ@10V,10A
- Package: TO-3P
- Manufacturer: Minos
