دیتاشیت IRFB7440PBF
مشخصات دیتاشیت
| نام دیتاشیت |
IRFB7440PBF
|
| حجم فایل |
86.727
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
10
|
مشخصات
-
RoHS:
true
-
Type:
N Channel
-
Category:
Triode/MOS Tube/Transistor/MOSFETs
-
Datasheet:
Infineon Technologies IRFB7440PBF
-
Operating Temperature:
-55°C~+175°C@(Tj)
-
Power Dissipation (Pd):
143W
-
Total Gate Charge (Qg@Vgs):
135nC@10V
-
Drain Source Voltage (Vdss):
40V
-
Input Capacitance (Ciss@Vds):
4730pF@25V
-
Continuous Drain Current (Id):
120A
-
Gate Threshold Voltage (Vgs(th)@Id):
3.9V@100uA
-
Drain Source On Resistance (RDS(on)@Vgs,Id):
2.5mΩ@10V,100A
-
Package:
TO-220
-
Manufacturer:
Infineon Technologies
