NX7002BKMYL دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
NX7002BKMYL
|
|
حجم فایل
|
56.899
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
16
|
مشخصات فنی
-
RoHS:
true
-
Type:
N Channel
-
Category:
Triode/MOS Tube/Transistor/MOSFETs
-
Datasheet:
Nexperia NX7002BKMYL
-
Operating Temperature:
-55°C~+150°C@(Tj)
-
Power Dissipation (Pd):
350mW;3.1W
-
Total Gate Charge (Qg@Vgs):
1nC@10V
-
Drain Source Voltage (Vdss):
60V
-
Input Capacitance (Ciss@Vds):
23.6pF@10V
-
Continuous Drain Current (Id):
350mA
-
Gate Threshold Voltage (Vgs(th)@Id):
2.1V@250uA
-
Reverse Transfer Capacitance (Crss@Vds):
3pF@30V
-
Drain Source On Resistance (RDS(on)@Vgs,Id):
2.2Ω@10V,200mA
-
Package:
DFN-3(0.6x1)
-
Manufacturer:
Nexperia
