K2543-VB دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
K2543-VB
|
|
حجم فایل
|
71.136
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
8
|
مشخصات فنی
-
RoHS:
true
-
Type:
N Channel
-
Category:
Triode/MOS Tube/Transistor/MOSFETs
-
Datasheet:
VBsemi Elec K2543-VB
-
Operating Temperature:
-55°C~+150°C@(Tj)
-
Power Dissipation (Pd):
106W
-
Total Gate Charge (Qg@Vgs):
43nC@10V
-
Drain Source Voltage (Vdss):
650V
-
Input Capacitance (Ciss@Vds):
1.6nF@100V
-
Continuous Drain Current (Id):
12A
-
Gate Threshold Voltage (Vgs(th)@Id):
5V@250uA
-
Reverse Transfer Capacitance (Crss@Vds):
200pF@100V
-
Drain Source On Resistance (RDS(on)@Vgs,Id):
650mΩ@10V,8A
-
Package:
TO-220F-3
-
Manufacturer:
VBsemi Elec
