دیتاشیت SI2307-TP
مشخصات دیتاشیت
| نام دیتاشیت |
SI2307-TP
|
| حجم فایل |
60.201
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
4
|
مشخصات
-
RoHS:
true
-
Type:
P Channel
-
Category:
Triode/MOS Tube/Transistor/MOSFETs
-
Datasheet:
MCC(Micro Commercial Components) SI2307-TP
-
Operating Temperature:
-55°C~+150°C@(Tj)
-
Power Dissipation (Pd):
1.1W
-
Total Gate Charge (Qg@Vgs):
6.2nC@4.5V
-
Drain Source Voltage (Vdss):
30V
-
Input Capacitance (Ciss@Vds):
340pF@15V
-
Continuous Drain Current (Id):
2.7A
-
Gate Threshold Voltage (Vgs(th)@Id):
3V@250uA
-
Reverse Transfer Capacitance (Crss@Vds):
-
-
Drain Source On Resistance (RDS(on)@Vgs,Id):
135mΩ@2.6A,4.5V
-
Package:
SOT-23(TO-236)
-
Manufacturer:
MCC(Micro Commercial Components)
